Technical Specifications
Property | Value |
Brand | DENSO |
Voltage (V) | 12 |
Amperage (A) | 175 |
Rotation | CW |
Pulley Type | Clutch |
Pulley Grooves | 6 |
Pulley Diameter (mm) | 52 |
OEM Cross Reference
Compatible OEM & aftermarket part numbers for direct replacement without modification:
Ford: CJ5T-10300-DB, CJ5Z-10346-A
Denso: 104210-6540
Lester: 12884, 12884N
Motorcraft: GL-8667
Arrowhead / J&N: 400-52435R, AND0627
PIC: 290-6317
WAI: 12884N
Interchangeable with all above part numbers, perfectly matching original mounting structure.
Product Highlights
Genuine Denso hairpin winding structure, 175A high output current under 12V voltage, clockwise (CW) rotation.
10 o'clock clock position, SD6 6-groove decoupler pulley (52mm outer diameter) to reduce belt vibration.
IR internal regulator + IF internal fan design, stable temperature control during long-term operation.
Remanufactured strictly per OEM dimensional standards, plug-and-play installation, no cutting or rewiring required.
Equipped with advanced Denso hairpin coil technology to cut energy loss and operating heat greatly, maintaining steady 12V charging voltage even under heavy electrical loads (car lights, navigation, air conditioning, multiple onboard electronics running simultaneously).
175A high amperage output easily satisfies power demand of turbo vehicles, prevents insufficient charging & dead battery issues during idling or city stop-and-go driving. The built-in decoupler pulley buffers engine vibration, protects the alternator internal structure and extends service life effectively. Internal cooling fan matches the heat generation curve perfectly to avoid overheating burnout in high-temperature engine bays.
Applications
FORD passenger vehicles & light commercial models:
Ford Escape 1.6L Turbo, 2013, 2014, 2015
Ford Transit Connect 1.6L Turbo, 2014, 2015
Additional compatible Ford vehicle models are available upon request.
Why Choose Our Alternators?
Strict OEM Specification Production
Every alternator is manufactured following original Denso factory parameters, consistent size, terminals and installation position ensure seamless direct replacement.
Long Service Life & Low Failure Rate
Premium copper hairpin winding, wear-resistant bearings and stable rectifier assembly greatly reduce breakdown risks, greatly lowering your after-sales maintenance cost.
Complete Matching Accessories
Support matching regulator, rectifier, brush holder and pulley spare parts for individual repair, saving replacement cost for repair shops.
Wide Compatibility
Crosses multiple brand OEM part numbers, one alternator covers numerous vehicle models to simplify your inventory stocking.
Strict Quality Inspection
All finished units undergo loading charging test, aging test and voltage detection before delivery to guarantee stable charging performance out of the box.
