Starter Motor for MITSUBA Lester 18759 OEM 5KM-81890-00-00 12V 0.6kw 9T

5 0 Reviews


Availability:

Quantity:

Inquire Add to Basket

12V 0.6KW 9T CCW PMDD starter, OEM replacement for Yamaha YFM ATVs (2002-2020).

Features:

Perfect OEM Match Identical specs to original MITSUBA unit: 9-tooth 14mm gear, 6mm unthreaded mounting holes, plug-and-play direct fit, no modification needed. Crosses Yamaha OEM 5KM-81890-00-00 & Lester 18759.
Stable PMDD Performance MITSUBA permanent magnet design delivers strong, consistent cranking power, durable against vibration and outdoor harsh conditions.
Broad Cross Reference Compatibility Interchangeable with Arrowhead, J&N, NAPA, REMY and all listed aftermarket part numbers, easy for parts lookup & stock management.
Wide Yamaha ATV Coverage Fits Yamaha YFM4/45/66/400/450/660 models from 2002 to 2020, ideal for ATV repair & aftermarket retail.

Product Description

Property	Value
Brand	MITSUBA
Voltage (V)	12
Kilowatt (kW)	0.6
Teeth	9
Rotation	CCW
Flange Diameter (mm)	84

Introduce:

The MITSUBA Starter Motor, Lester 18759 OEM 5KM-81890-00-00, is engineered to provide a dependable starting solution for a variety of Yamaha vehicles. Operating at 12 volts and delivering 0.6 kilowatts, this starter motor is designed to efficiently crank the engine with its 9-teeth engagement. The counterclockwise (CCW) rotation ensures compatibility with the engine's mechanical specifications for smooth and effective starting.

This starter motor is tailored for use with multiple Yamaha models, including the Rhino 450 YXR450F Utility Vehicle (UTV) from 2006 to 2009, the Rhino 660 YXR660F UTV from 2004 to 2007, and an array of Grizzly, Kodiak, and Wolverine All-Terrain Vehicles (ATVs) spanning several years. The 84mm flange diameter complements the design of these vehicles, ensuring a proper fit and ease of installation.

Constructed for durability, this starter motor is designed to reduce battery load and improve the vehicle's overall performance. Its direct fit design simplifies the installation process, making it accessible for both professional mechanics and DIY users.

This MITSUBA starter motor (Lester 18759, OEM 5KM-81890-00-00, 12V 0.6KW 9T) is widely compatible with multiple brands of all-terrain vehicles (ATVs) and utility vehicles, detailed applications are as follows:

1. Yamaha ATV & Utility Vehicles

It fits a full range of Yamaha models with clear year and displacement coverage, being a direct factory replacement part.

YFM400 Series (401cc): Grizzly 4x4 Auto, Kodiak 4x4, covering production years 2001–2008.
YFM450 Series (421cc): Grizzly 4x4 Auto, Kodiak 450 (including EPS, Hunter and special editions), Wolverine 4x4, applicable to 2003–2024 models.
YFM660 Series (660cc): Grizzly 4x4 for 2002–2008.
Rhino Utility Vehicles: YXR45F Rhino 450 (2006–2009) and YXR66F Rhino 660 & its various special editions (2004–2007).

2. Coleman ATV

Compatible with Coleman Outfitter 500 ATV.

3. Hisun ATV & Utility Vehicles

ATV: HS500, HS500-2, HS700, RX500.
Utility Vehicles: 500 4x4, 700 4x4 (2012–2015), 700 Mayhem.

4. Nordik ATV & Utility Vehicles

ATV: NK 700 L.
Utility Vehicles: NK 500 U EFI, NK 700 U, NK 700 U 4-Pass.

FAQ:

Q1. How long is your delivery time?

A: Generally it takes 45-60 days if the goods are out of stock. If it is in stock, it takes 7 days.

Q2. Do you provide samples ? is it free or extra ?

A: We can provide samples, but we don't take charge of the cost of the sample and the freight cost.

Q3. What are your terms of packing?

A: Generally, we pack our goods in neutral cartons. If you have a legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q4. Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery.

Q5.How about your warranty?

A:Our warranty is one year.

Model

OEM	OEM Reference
LESTER	18759
PIC	191-378
BARSANCO	620-134
BBB SMALL MOTOR	22-18759
EMS	YA-107N
HI LEVEL	STY0263
MINNPAR	57-2720
MPA SMALL MOTOR	P177N
NAPA SMALL MOTOR	RN18759
RCP	ST-18759
REMY SMALL MOTOR	RS41234
STOCKERS STARTERS	YA-107
TUCKER ROCKY	495754
TUCKER ROCKY	49-5754
WILSON SMALL ENGINE	71-26-18759
YAMAHA	5KM-81890-00-00

Applicable Models

Make	Model	Type	Year
YAMAHA	Rhino 450 YXR450F	Utility Vehicle (UTV)	2006
YAMAHA	Rhino 450 YXR450F	Utility Vehicle (UTV)	2007
YAMAHA	Rhino 450 YXR450F	Utility Vehicle (UTV)	2008
YAMAHA	Rhino 450 YXR450F	Utility Vehicle (UTV)	2009
YAMAHA	Rhino 660 YXR660F	Utility Vehicle (UTV)	2004
YAMAHA	Rhino 660 YXR660F	Utility Vehicle (UTV)	2005
YAMAHA	Rhino 660 YXR660F	Utility Vehicle (UTV)	2006
YAMAHA	Rhino 660 YXR660F	Utility Vehicle (UTV)	2007
YAMAHA	Grizzly 400 4WD YFM40FB	All-Terrain Vehicle (ATV)	2007
YAMAHA	Grizzly 400 4WD YFM40FB	All-Terrain Vehicle (ATV)	2008
YAMAHA	Grizzly 400 4WD Hunter YFM40FBH	All-Terrain Vehicle (ATV)	2007
YAMAHA	Grizzly 400 4WD Hunter YFM40FBH	All-Terrain Vehicle (ATV)	2008
YAMAHA	Grizzly 400 4WD IRS YFM40FB	All-Terrain Vehicle (ATV)	2007
YAMAHA	Grizzly 400 4WD IRS Hunter YFM40FBH	All-Terrain Vehicle (ATV)	2007
YAMAHA	Grizzly 450 4WD YFM45FG	All-Terrain Vehicle (ATV)	2007
YAMAHA	Grizzly 450 4WD YFM45FG	All-Terrain Vehicle (ATV)	2008
YAMAHA	Grizzly 450 4WD YFM45FG	All-Terrain Vehicle (ATV)	2009
YAMAHA	Grizzly 450 4WD YFM45FG	All-Terrain Vehicle (ATV)	2010
YAMAHA	Grizzly 450 4WD Hunter YFM45FGH	All-Terrain Vehicle (ATV)	2007
YAMAHA	Grizzly 450 4WD Hunter YFM45FGH	All-Terrain Vehicle (ATV)	2008
YAMAHA	Grizzly 450 4WD Hunter YFM45FGH	All-Terrain Vehicle (ATV)	2009
YAMAHA	Grizzly 450 4WD Hunter YFM45FGH	All-Terrain Vehicle (ATV)	2010
YAMAHA	Grizzly 450 Outdoorsman Edition YFM45FGOH	All-Terrain Vehicle (ATV)	2007
YAMAHA	Grizzly 450 Special Edition YFM45FGSP	All-Terrain Vehicle (ATV)	2008
YAMAHA	Grizzly 450 Special Silver Edition YFM45FGSE	All-Terrain Vehicle (ATV)	2007
YAMAHA	Grizzly 660 YFM660F	All-Terrain Vehicle (ATV)	2002
YAMAHA	Grizzly 660 YFM660F	All-Terrain Vehicle (ATV)	2003
YAMAHA	Grizzly 660 YFM660F	All-Terrain Vehicle (ATV)	2004
YAMAHA	Grizzly 660 YFM660F	All-Terrain Vehicle (ATV)	2005
YAMAHA	Grizzly 660 YFM660F	All-Terrain Vehicle (ATV)	2006
YAMAHA	Grizzly 660 YFM660F	All-Terrain Vehicle (ATV)	2007
YAMAHA	Grizzly 660 YFM660F	All-Terrain Vehicle (ATV)	2008
YAMAHA	Kodiak 400 2WD YFM400A	All-Terrain Vehicle (ATV)	2003
YAMAHA	Kodiak 400 2WD YFM4A	All-Terrain Vehicle (ATV)	2004
YAMAHA	Kodiak 400 4WD YFM400FA	All-Terrain Vehicle (ATV)	2003
YAMAHA	Kodiak 400 4X4 YFM4FA	All-Terrain Vehicle (ATV)	2004
YAMAHA	Kodiak 400 4WD YFM4FA	All-Terrain Vehicle (ATV)	2005
YAMAHA	Kodiak 400 4WD YFM4FA	All-Terrain Vehicle (ATV)	2006
YAMAHA	Kodiak 400 4X4 Camo Hardwoods YFM400FAH	All-Terrain Vehicle (ATV)	2003
YAMAHA	Kodiak 400 Hunter YFM4FAH	All-Terrain Vehicle (ATV)	2004
YAMAHA	Kodiak 400 4WD Hunter YFM4FAH	All-Terrain Vehicle (ATV)	2005
YAMAHA	Kodiak 400 4WD Hunter YFM4FAH	All-Terrain Vehicle (ATV)	2006
YAMAHA	Kodiak 450 4WD YFM450FA	All-Terrain Vehicle (ATV)	2003
YAMAHA	Kodiak 450 4x4 YFM45FA	All-Terrain Vehicle (ATV)	2004
YAMAHA	Kodiak 450 4WD YFM45FA	All-Terrain Vehicle (ATV)	2005
YAMAHA	Kodiak 450 4WD YFM45FA	All-Terrain Vehicle (ATV)	2006
YAMAHA	Kodiak 450 4x4 Hardwoods YFM45FAH	All-Terrain Vehicle (ATV)	2004
YAMAHA	Kodiak 450 4WD Hunter YFM45FAH	All-Terrain Vehicle (ATV)	2005
YAMAHA	Kodiak 450 4WD Hunter YFM45FAH	All-Terrain Vehicle (ATV)	2006
YAMAHA	Kodiak 450 4WD YFM45KD	All-Terrain Vehicle (ATV)	2018
YAMAHA	Kodiak 450 4WD YFM45KD	All-Terrain Vehicle (ATV)	2019
YAMAHA	Kodiak 450 4WD YFM45KD	All-Terrain Vehicle (ATV)	2020
YAMAHA	Kodiak 450 4WD Hunter YFM45KDH	All-Terrain Vehicle (ATV)	2018
YAMAHA	Kodiak 450 4WD Hunter YFM45KDH	All-Terrain Vehicle (ATV)	2019
YAMAHA	Kodiak 450 4WD Hunter YFM45KDH	All-Terrain Vehicle (ATV)	2020
YAMAHA	Kodiak 450 4WD Special Edition YFM45FAS	All-Terrain Vehicle (ATV)	2006
YAMAHA	Kodiak 450 EPS 4WD YFM45KP	All-Terrain Vehicle (ATV)	2018
YAMAHA	Kodiak 450 EPS 4WD YFM45KP	All-Terrain Vehicle (ATV)	2019
YAMAHA	Kodiak 450 EPS 4WD YFM45KP	All-Terrain Vehicle (ATV)	2020
YAMAHA	Kodiak 450 EPS 4WD Hunter YFM45KP	All-Terrain Vehicle (ATV)	2018
YAMAHA	Kodiak 450 EPS 4WD Hunter YFM45KP	All-Terrain Vehicle (ATV)	2019
YAMAHA	Kodiak 450 EPS 4WD Hunter YFM45KP	All-Terrain Vehicle (ATV)	2020
YAMAHA	Kodiak 450 EPS SE YFM45KPS	All-Terrain Vehicle (ATV)	2020
YAMAHA	Kodiak 450 Real Tree YFM450FAH	All-Terrain Vehicle (ATV)	2003
YAMAHA	Wolverine 450 4WD YFM45FX	All-Terrain Vehicle (ATV)	2008
YAMAHA	Wolverine 450 4WD YFM45FX	All-Terrain Vehicle (ATV)	2009
YAMAHA	Wolverine 450 4WD YFM45FX	All-Terrain Vehicle (ATV)	2010
YAMAHA	Wolverine 450 4x4 Sport YFM45FX	All-Terrain Vehicle (ATV)	2006
YAMAHA	Wolverine 450 4x4 Sport YFM45FX	All-Terrain Vehicle (ATV)	2007
YAMAHA	Wolverine 450 4x4 Sport SE YFM45FXSE	All-Terrain Vehicle (ATV)	2007
YAMAHA	Wolverine 450 4x4 Sport SE YFM45FXSE	All-Terrain Vehicle (ATV)	2008
